Description

• Max. Speed (RPM): 6400 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 15.00mm
• Air Flow: 16.24 CFM (0.460 m3/min)
• Static Pressure: 0.315 inchH2O (8.00 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: —
• Noise: 36.0 dB(A)
• Power (Watts): 1.56 W
• RPM: 6400 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.12 A
• Material Frame: 7.0 – 14.0 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB0512HHB.jpg
• Unnamed: 34: /Download/3D/AFB0512HHB.stp
