Description

• Max. Speed (RPM): 8200 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 25.40mm
• Air Flow: 46.16 CFM (1.307 m3/min)
• Static Pressure: 0.774 inchH2O (19.66 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: —
• Noise: 52.5 dB(A)
• Power (Watts): 8.28 W
• RPM: 8200 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): —
• Voltage Rating: 0.69 A
• Material Frame: 7.0 – 14.0 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: —
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB60x25_31.png
• Unnamed: 34: /Download/3D/AFB0612UH-A.stp
