Description

• Max. Speed (RPM): 3800 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 13.00mm
• Air Flow: 31.01CFM (0.878 m3/min)
• Static Pressure: 0.148 inchH2O (3.75 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: Speed Sensor (Tach)
• Noise: 35.0 dB(A)
• Power (Watts): 2.64 W
• RPM: 3800 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.22 A
• Material Frame: 7.0 – 14.0 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB70x20mm_25.png
• Unnamed: 34: /Download/3D/AFB0712HC-F00.stp
