Description

• Max. Speed (RPM): 3700 RPM
• Part Status: Active
• Voltage Rated: 24 VDC
• Width: 15.00mm
• Air Flow: 39.20 CFM (1.110 m3/min)
• Static Pressure: 0.188 inchH2O (4.77 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: Locked Rotor Sensor
• Noise: 39.5 dB(A)
• Power (Watts): 2.88 W
• RPM: 3700 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): —
• Voltage Rating: 0.12 A
• Material Frame: 14.0 – 27.6 VDC
• Material Blade: Plastic
• Lifetime @ Temp: —
• Image Filename: —
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB0824HHB_1.jpg
