Description

• Ingress Protection: IP56
• Max. Speed (RPM): 4600 RPM
• Part Status: Active
• Voltage Rated: 24 VDC
• Width: 38.00mm
• Air Flow: 212.573CFM (6.019m3/min)
• Static Pressure: 0.844 inchH2O (21.427 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 58.5 dB(A)
• Power (Watts): 20.40 W
• RPM: 4600 RPM
• Termination: 4 lead wires
• Operating Temperature: IP56
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.85 A
• Material Frame: 21.6-26.4VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB1248_AFB120X38mm-C_9.jpg
• Unnamed: 34: /Download/3D/AFB1224EHE-EP.stp
