Description

• Max. Speed (RPM): 3200 RPM
• Part Status: Active
• Voltage Rated: 48 VDC
• Width: 38.00mm
• Air Flow: 129.96 CFM (3.680 m3/min)
• Static Pressure: 0.420 inchH2O (10.70 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: —
• Noise: 48.0 dB(A)
• Power (Watts): 8.64 W
• RPM: 3200 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.18 A
• Material Frame: 28.0 – 56.0 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/A/F/AFB1248H_AFB120x38mm_6.jpg
• Unnamed: 34: /Download/3D/AFB1248VHE.stp
