Description

• Series: AFC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 7200 RPM
• Certification: CSA.pdf,VDE.pdf,UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 15.00mm
• Air Flow: 29.24CFM (0.828 m3/min)
• Static Pressure: 0.517 inchH2O (13.12 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 47.5 dB(A)
• Power (Watts): 3.96 W
• RPM: 7200 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.33 A
• Material Frame: 8.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
