Description

• Series: AFC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 6000 RPM
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 15.00mm
• Air Flow: 41.95 CFM (1.188 m3/min)
• Static Pressure: 0.327 inchH2O (8.308 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 46.5 dB(A)
• Power (Watts): 4.20 W
• RPM: 6000 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.35 A
• Material Frame: 8.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
