Description

• Series: AFC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 7500 RPM
• Certification: CSA.pdf,VDE.pdf,UL.pdf
• Part Status: Active
• Voltage Rated: 48 VDC
• Width: 38.00mm
• Air Flow: 159.36CFM (4.515 m3/min)
• Static Pressure: 1.528 inchH2O (38.082 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 67.0 dB(A)
• Power (Watts): 28.80 W
• RPM: 7500 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -40~+65⁰C
• Voltage Rating: 0.60 A
• Material Frame: 36.0 – 75.0VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
