Description

• Series: AFL
• Protection/ Option: Electrical
• Ingress Protection: IP52
• Certification: UL/CSA/CE/TUV/ATEX
• Part Status: Active
• Voltage Rated: 110VAC / 240VAC (50/60Hz)
• Width: 38.00mm
• Air Flow: 103.60 CFM (2.930 m3/min)
• Static Pressure: 0.400 inchH2O (10.16 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: —
• Noise: 45.0 dB(A)
• Power (Watts): 4.60 W
• RPM: 3200 RPM
• Termination: 2 lead wires
• Operating Temperature: IP52
• Weight gram (g): -40~+60⁰C
• Voltage Rating: —
• Material Frame: 110 – 240 VAC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
• Main Speed (RPM): 3200
• Fan Dimension(mm): 120x120x38 mm
