Description

• Series: AUB
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 4800 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 15.00mm
• Air Flow: 12.36 CFM (0.350 m3/min)
• Static Pressure: 0.181 inchH2O (4.60 mmH2O)
• Bearing Type: Superflo
• Fan Type: Axial
• Features: Speed Sensor (Tach)
• Noise: 28.0 dB(A)
• Power (Watts): 0.96 W
• RPM: 4800 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.08 A
• Material Frame: 7.0 – 13.8 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 50000 Hrs@40⁰C
