Description

• Series: AUB
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 3900 RPM
• Certification: UL-AUB0812H-E.pdf,CE-AUB0812H-E.pdf,TUV-AUB0812H-E.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 25.40mm
• Air Flow: 50.15 CFM (1.421 m3/min)
• Static Pressure: 0.239 inchH2O (6.08 mm H2O)
• Bearing Type: Sleeve
• Fan Type: Axial
• Features: Speed Sensor (Tach)
• Noise: 37.5 dB(A)
• Power (Watts): 2.76 W
• RPM: 3900 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+85⁰C
• Voltage Rating: 0.23 A
• Material Frame: 5.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 50000 Hrs@85⁰C
