Description

• Series: AUB
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 4600 RPM
• Certification: UL-CSA-AUB0912HJ-00.pdf,TUV-AUB0912HJ-00.pdf,CE-AUB0912HJ-00.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 25.40mm
• Air Flow: 69.02CFM (1.955 m3/min)
• Static Pressure: 0.407 inchH2O (10.340 mm H2O)
• Bearing Type: Sleeve
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 45.0 dB(A)
• Power (Watts): 4.20 W
• RPM: 4600 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+85⁰C
• Voltage Rating: 0.35 A
• Material Frame: 10.8 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 50000 Hrs@85⁰C
