Description

• Series: AUC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 7400 RPM
• Certification: CSA.pdf,VDE.pdf,UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 15.00mm
• Air Flow: 20.22CFM (0.572 m3/min)
• Static Pressure: 0.299 inchH2O (7.58 mmH2O)
• Bearing Type: Superflo
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 38.5 dB(A)
• Power (Watts): 2.16 W
• RPM: 7400 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.18 A
• Material Frame: 7.0 – 14.0 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 30000 Hrs@40°C
