Description

• Max. Speed (RPM): 7500 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 10.00mm
• Air Flow: 1.84 CFM (0.052 m3/min)
• Static Pressure: 0.335 inchH2O (8.50 mmH2O)
• Bearing Type: Ball
• Fan Type: Blower
• Features: Speed Sensor (Tach)
• Noise: 29.0 dB(A)
• Power (Watts): 0.96 W
• RPM: 7500 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.08 A
• Material Frame: 10.8 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: —
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/B/F/BFB35x35x10mm_32.png
• Unnamed: 34: /Download/3D/BFB03512HA-CF00.stp
