Description

• Max. Speed (RPM): 4000 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 33.00mm
• Air Flow: 34.28 CFM (0.971 m3/min)
• Static Pressure: 1.564 inchH2O (39.70 mmH2O)
• Bearing Type: Ball
• Fan Type: Blower
• Features: —
• Noise: 57.0 dB(A)
• Power (Watts): 15.00 W
• RPM: 4000 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 1.25 A
• Material Frame: 7.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: —
• Image Filename: 50000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/B/F/BFB1012-A_2.png
• Unnamed: 34: /Download/3D/BFB1012HH-A.STP
