Description

• Max. Speed (RPM): 6300 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 20.00mm
• Air Flow: 7.17 CFM (0.203 m3/min)
• Static Pressure: 0.218 inchH2O (5.54 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: Locked Rotor Protection
• Noise: 24.0 dB(A)
• Power (Watts): 0.72 W
• RPM: 6300 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.06 A
• Material Frame: 7.0 – 13.8 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/E/F/EFB40x40x20_5.jpg
• Unnamed: 34: /Download/3D/EFB0412MD.stp
