Description

• Max. Speed (RPM): 2300 RPM
• Part Status: Active
• Voltage Rated: 24 VDC
• Width: 15.00mm
• Air Flow: 29.62CFM (0.839 m3/min)
• Static Pressure: 0.067 inchH2O (01.71 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: —
• Noise: 30.0 dB(A)
• Power (Watts): 1.92 W
• RPM: 2300 RPM
• Termination: 2 lead wires
• Operating Temperature: —
• Weight gram (g): —
• Voltage Rating: 0.08 A
• Material Frame: 14.0 – 27.6 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: —
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/E/F/EFB80x80x15mm_10.jpg
• Unnamed: 34: /Download/3D/EFB0824LB.stp
