Description

• Series: EFC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 5500 RPM
• Ingress Protection: IP55
• Part Status: Active
• Voltage Rated: 48 VDC
• Width: 50.80mm
• Air Flow: 415.66CFM (11.770 m3/min)
• Static Pressure: 1.771 inchH2O (44.99 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 63.4 dB(A)
• Power (Watts): 59.04 W
• RPM: 5500 RPM
• Termination: 4 lead wires
• Operating Temperature: IP55
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 1.23 A
• Material Frame: 28.0 – 53.0VDC
• Material Blade: Die-Cast Alum
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
