Description

• Series: EUB
• Ingress Protection: IP51
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 39.00mm
• Air Flow: 79.867 CFM (2.260 m3/min)
• Static Pressure: 0.184 inchH2O (4.660 mm H2O)
• Bearing Type: Sleeve
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 32.0 dB(A)
• Power (Watts): 1.56 W
• RPM: 2200 RPM
• Termination: 4 lead wires
• Operating Temperature: -40~+40⁰C
• Weight gram (g): 190.0 g
• Voltage Rating: 10.8 – 13.2 VDC
• Material Frame: Plastic
• Material Blade: Plastic
• Lifetime @ Temp: 30000 Hrs@40°C
• Image Filename: eub1312he-10p1.png
• Power (W): 1.56 W
• Voltage (VDC): 12 VDC
• Air Pressure(in H2O): 0.184 inchH2O (4.660 mm H2O)
• Air Flow (CFM): 79.867 CFM (2.260 m3/min)
• Dimension(mm): 125x125x39 mm
• Operating Voltage Range (VDC): 10.8 – 13.2 VDC
• Noise (dB-A): 32.0 dB(A)
• Speed (RPM): 2200 RPM
