Description

• Max. Speed (RPM): 10000 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 28.00mm
• Air Flow: 12.44 CFM (0.352 m3/min)
• Static Pressure: 0.566 inchH2O (14.38 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: Speed Sensor (Tach)
• Noise: 45.0 dB(A)
• Power (Watts): 3.00 W
• RPM: 10000 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.25 A
• Material Frame: 7.0 – 13.8 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 50000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/F/F/FFB03812MN-F00_1.jpg
• Unnamed: 34: /Download/3D/FFB03812MN-F00.stp
