Description

• Max. Speed (RPM): 18000 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 28.00mm
• Air Flow: 23.66CFM (0.670 m3/min)
• Static Pressure: 2.33 inchH2O (59.18 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 56.5 dB(A)
• Power (Watts): 6.60 W
• RPM: 18000 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -40~+80⁰C
• Voltage Rating: 0.83 A
• Material Frame: 5.0 – 13.8 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/f/f/ffb0412vn-00.jpg
• Unnamed: 34: /Download/3D/FFB0412VN-00.stp
