Description

• Max. Speed (RPM): 4500 RPM
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 25.40mm
• Air Flow: 67.02 CFM (1.898 m3/min)
• Static Pressure: 0.392 inchH2O (9.955 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: Locked Rotor Sensor
• Noise: 48.6 dB(A)
• Power (Watts): 6.00 W
• RPM: 4500 RPM
• Termination: 3 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 0.50 A
• Material Frame: 4.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40⁰C
• Spec Sheet: https://www.delta-fan.com/pub/media/catalog/product/cache/6360e336b2a70951114dbd37294096ee/f/f/ffb80x80x25.4_3.jpg
