Description

• Series: GFC
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 15000 RPM
• Certification: GFC0848SS-00EQR_UL.pdf,GFC0848SS-00EQR_TUV.pdf
• Part Status: Active
• Voltage Rated: 48 VDC
• Width: 56.00mm
• Air Flow: 135.73 CFM (3.844m3 / min)
• Static Pressure: 6.347inchH2O (161.21mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 79.0 dB(A)
• Power (Watts): 57.60 W
• RPM: 15000 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 1.20 A
• Material Frame: 36.0 – 60.0VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
