Description

• Series: GFM
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 19000 RPM
• Certification: CSA.pdf,VDE.pdf,UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 56.00mm
• Air Flow: 21.56CFM (0.610 m3/min)
• Static Pressure: 3.416 inchH2O (86.78 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 68.5 dB(A)
• Power (Watts): 12.60 W
• RPM: 19000 RPM
• Termination: 8 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 1.10 A
• Material Frame: 10.8 – 12.6 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
