Description

• Series: GFM
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 12500 RPM
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 56.00mm
• Air Flow: 93.23 CFM (2.640 m3/min)
• Static Pressure: 4.485inchH2O (113.91mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 73.3 dB(A)
• Power (Watts): 28.80 W
• RPM: 12500 RPM
• Termination: 8 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 2.40 A
• Material Frame: 10.8 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 50000 Hrs@40⁰C
