Description

• Series: HEH
• Ingress Protection: IP20 (IEC60529)
• Image Filename: heh070pa.png
• Approvals: UL Recognized, CE
• Indoor / Outdoor: Indoor
• Dimensions(inch): 5.9H x 5.7W x 1.8D
• Weight(lbs / kg): 1.1 / 0.5
• Dimensions(mm): 150H x 145W x 45D
• Rated Voltage(VDC): 48VDC
• Cooling/heating Capacity: 700 W heating
• Dimensions (inch): 5.9H x 5.7W x 1.8D
• Dimensions (mm): 150H x 145W x 45D
• Noise (dB-A) @1.5M: —
• Operating Current (A): 14.5
• Rated Voltage: 48VDC
• Weight (lbs / kg): 1.1 / 0.5
• Rated Current(A): 14.5
• HeatingCapacity (W): 700 W heating
