Description

• Series: IMA
• Description: Safety approval for Medical (IEC 60601-1-2 and 3rd+A1 edition CB report) TUV EN60601-1:2006 CAN / CSA-C22.2 NO.60601-1 + ANSI / AAMI, ES 60601-1, 3000m altidude, 100-240Vac only Industrial (IEC 62368) and IT IEC60950-1 CB report, IEC62368-1 CB report, TUV EN62368-1, UL62368-1 and CAN / CSA C22.2 No. 62368-1 3000 Watt peak power (up to 5s) Standby power < 2 Watt • Wide operating input voltage range: 80 Vac to 275 Vac or 120 Vdc to 300 Vdc • Wide adjustable output voltage range (+ • - 20%) Standby output 5 Vdc • 2 A High efficiency: up to 94% Size: 309.6 x 127 x 40.6 mm (12.2 x 5 x 1.6 in) (1U design) • Low acoustic noise level of less than 39 dB(A), variable speed fan control Active current sharing 2 x MOPP and BF appliances PMBus™ compatible for control, programming and monitoring 500,000 hour MTBF Optional conformal coating 3 years warranty • Featured: No
