Description

• Series: PFM
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 6500 RPM
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 38.00mm
• Air Flow: 282.31CFM (7.994 m3/min)
• Static Pressure: 2.033 inchH2O (51.65 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 70.0 dB(A)
• Power (Watts): 46.80 W
• RPM: 6500 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+60⁰C
• Voltage Rating: 3.90 A
• Material Frame: 10.8 – 12.8 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
