Description

• Series: PFR
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 14500 RPM
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 38.00mm
• Air Flow: 65.98 CFM (1.868 m3/min)
• Static Pressure: 2.502 inchH2O (63.56 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 63.3 dB(A)
• Power (Watts): 19.20 W
• RPM: 14500 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 1.60 A
• Material Frame: 7.0 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
