Description

• Series: PMU
• Description: AC input voltage range selectable by switch
• CurrentNormal condition LED indicator（Green）、Battery reverse polarity alarm（Red）
• OnACSeamless switchover on power losstoBatteryoperating
• Compliant withHarmonic current IEC / EN 61000-3-2, Class A
• standard
• Mean Time Between Failuresoperatingtime (MTBF) > 700,000
• Hours，Telcordia SR-332
• standard
• ACNormal、DC normalandLowBattery signal monitoring
• Overvoltage
• OverCurrent
• Over-temperature
• Short circuitprotection
• buffer（Discharge）modeatBuilt-inTypeOverCurrentandShort circuitProtect
• PassOver IEC / EN / UL 62368-1
• Certification ** NRND ** PMU-13V155WLBA, PMU-13V155WLCA
• Featured: No
