Description

• Series: QFR
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 4200 RPM
• Certification: CSA.pdf,VDE.pdf,UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 25.40mm
• Air Flow: 70.24 CFM (1.989 m3/min)
• Static Pressure: 0.551 inchH2O (13.99 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 45.0 dB(A)
• Power (Watts): 4.80 W
• RPM: 4200 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.40 A
• Material Frame: 10.8 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
