Description

• Series: THB
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 8300 RPM
• Ingress Protection: IP55
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 24 VDC
• Width: 25.40mm
• Air Flow: 174.73CFM (4.948 m3/min)
• Static Pressure: 2.139 inchH2O (54.33 mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 65.0 dB(A)
• Power (Watts): 22.80 W
• RPM: 8300 RPM
• Termination: 4 lead wires
• Operating Temperature: IP55
• Weight gram (g): -10~+70⁰C
• Voltage Rating: 0.95 A
• Material Frame: 18.0 – 27.5 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
