Description

• Series: THD
• Impeller Diameter (mm): 10.0
• Max. Speed (RPM): 19500 RPM
• Certification: UL.pdf
• Part Status: Active
• Voltage Rated: 12 VDC
• Width: 38.00mm
• Air Flow: 80.54 CFM (2.278m3/min)
• Static Pressure: 4.43inchH2O (112.52mmH2O)
• Bearing Type: Ball
• Fan Type: Axial
• Features: PWM Control, Speed Sensor (Tach)
• Noise: 66.0 dB(A)
• Power (Watts): 34.80 W
• RPM: 19500 RPM
• Termination: 4 lead wires
• Operating Temperature: —
• Weight gram (g): -40~+70⁰C
• Voltage Rating: 2.90 A
• Material Frame: 10.2 – 13.2 VDC
• Material Blade: Plastic
• Lifetime @ Temp: Plastic
• Image Filename: 70000 Hrs@40°C
